GReddy TRUST Japan Bolt-on turbo kit, TF035HL, with catalytic converter, manual for Suzuki Jimny JB74W K15B, 11590411
GReddy TRUST Japan Bolt-on turbo kit, TF035HL, with catalytic converter, manual for Suzuki Jimny JB74W K15B, 11590411
Regular price
£4,039.20
Regular price
Sale price
£4,039.20
Taxes included.
Shipping calculated at checkout.
SKU:11590411
Quantity
Couldn't load pickup availability
Bolt-on turbo kit for the Suzuki Jimny JB74W with the K15B engine, built around a TF035HL 14GK turbo with a 6 cm² turbine housing, with a catalytic converter. The kit includes a stainless steel lost-wax exhaust manifold, a TYPE41 intercooler, an Airinx S size air filter and aluminium compression and suction tubes.
Fitment
| Make | Model | Chassis | Engine | Years |
|---|---|---|---|---|
| Suzuki | Jimny (Manual) | JB74W | K15B |
Specifications
| Part number | 11590411 |
|---|---|
| Made by | TRUST, Japan |
| Turbine | TF035HL 14GK |
| Turbine housing area | 6 cm² |
| Exhaust manifold | Stainless steel, lost-wax |
| Front pipe | Stainless steel, 50 mm, with catalytic converter |
| Intercooler | TYPE41 |
| Air filter | Airinx, S size |
| Compression tube | Aluminium, 50 mm to 60 mm |
| Suction tube | Aluminium, 50 mm |
| Other | Short parts set |
Notes: Low viscosity oil (0W-16, 0W-20) cannot be used, SAE 5W-30 is recommended. The genuine oil pan must be drilled. The genuine washer tank cannot be fitted. Spark plugs must be changed to a heat range equivalent to No. 8. The genuine catalytic converter cannot be fitted. ECU rewriting is required.
Fitment help: call +44 20 3388 8444 or contact us.
